Our new luxury Orca model

Insulation

• 1 x base layer aluminium bubble insulation.
• All season insulation with closed cell PIR board
• Soft wool
• Panelled white walls
• Slatted wood ceiling

Cab

• Double passenger seat (can be swapped for a single passenger seat for an extra £900+VAT)
• Reversing camera with 2 views (directly behind & birds eye)
• Handmade drop down curtain separating cab from living area
• Engine battery cut off switch (to prevent battery drain when not in use and anti-theft device)

Berths and seating

• 4 berths in total
• 1 x 191 cm x 135 cm double fixed bed at rear
• 1 x 180 cm x 50 cm single bed running across the van
• 1 x 195 cm x 53 cm single bed running by sliding door
• Seating – 4 seats in total (3 in cab and 1 in rear) all forward facing with 3 point seat belts. Rear seat is ISO fix (can be made up to 5 seats, 2 being ISO fix for an extra £1050+VAT)

Rear living area

• 191 cm x 135 cm fixed slatted bed
• CRX65 12v fridge/freezer.
• 2 x MaxxAir deluxe fan with fly screen and shades
• Garage area with heavy duty rubber matting (contains solar set up – see specs to the right)
• 2 x USB sockets
• 2 x LED reading lights with inbuilt USB sockets

Main living area

Multi-configuration dining area with unique swivel box seats and Lagun swivel table offering the following choices:

• 1 x large ‘L shaped’ seating/dining area – 180 cm x 195 cm
• 2 x separate dinette areas.
• 1 x dinette by sliding door + 1 bench seat widthways.
• 1 x dinette widthways + 1 bench seat by sliding door.
• Area converts to 2 single beds.
• Aguti fold away/removable seat with an integrated 3 point seat belt built into the dining area.
• Digital marine water tank level meter (highly accurate as measures water pulled through pipes).
• Truma Combi 2E heater/boiler (works on LPG or 230v electric).
• Slide out, solid wood dining table with extra heavy duty brackets.
• Solid wood window sills on all 5 windows.
• Eye level open storage on each side.
• Rich walnut trim features running throughout the living area.
• Apple/Android wireless phone/smart watch charger.
• 6 x touch sensitive ceiling LED spot lights.
• 3 x double 230 v sockets

Kitchen

• Thetford triplex gas oven, grill and 3 ring hob
• MaxxAir deluxe fan with fly screen and shade
• Solid wood kitchen worktop with double sink insert/chopping board
• Full size domestic sink
• Black domestic tap with multi directional hose
  Full height kitchen splash back
• Slatted real wood feature separating kitchen area from single dining seat
• Under sink cupboards, soft close drawers, soft close cutlery drawer with bamboo divider
• 2 x eye level soft close wall cupboards
• Under cabinet touch sensitive LED spotlights over the kitchen.

Front

• Spacious shower room with reco walls, space saving concertina door, and hand made duck board.
• LED light in shower room.
• Micro Heki rooflight.
• Matching black shower head and mixer tap.
• Nature’s Head composting toilet (removable) with electric fan.

Solar

• Victron mains charger.
• Victron 50amp MPPT smart solar controller (with full bluetooth connectivity via smartphone app).
• Victron BMV battery monitor in living area showing battery time remaining at current use (with full bluetooth connectivity via smartphone app).
• Victron DC-DC alternator (charges leisure batteries while driving)
• Victron 500w inverter connected to a double 240v socket (with full bluetooth connectivity via smartphone app)
• 220Ah AGM leisure batteries.
• 270w solar panel
• 240v hook up for when on campsites/mains electric available (charges leisure batteries also)

Exterior

• Sliding tinted window in sliding door.
• 2 x fixed tinted windows on rear doors
• 2 x sliding windows either side of the fixed bed.
• Fiamma F80s awning.
• Awning LED light and rain protector rail.
• Thule electric slide out step.
• 25 litre underslung LPG gas tank with electrical on board on/off switch and level gauge.
• 1 x 83 litre fresh water tank (fully winterized down to -25c with insulation and automatic defrost element).
• 1 x 60 litre grey water tank (fully winterized down to -25c with insulation and automatic defrost element).

Soft furnishings

• Handmade drop-down cab curtain
• Handmade drop-down curtains on all windows
• Premium seat cushions
• Premium foam mattress
